Outback TankLink Wireless Tank Level Float Switch
Monitor your tank level and automatically control your solar pump — without running a control cable from the tank back to the pump.
Including GST. Free shipping on orders Australia-Wide*
Australia Wide
AustralianOwned
Support
Warranty
We design solar pumping systems to suit your needs.
Get a free quote ›Powerful. Reliable. Built for the Outback.
Wireless tank level monitoring and automatic pump control — configured and ready to connect to your Outback Solar Pump system.
The Outback TankLink Wireless Tank Level Control System is designed for remote tanks, bores and livestock watering systems where running traditional float-switch cable between the tank and pump is difficult, expensive or simply impractical.
TankLink uses a non-contact ultrasonic level sensor mounted above the water tank to continuously measure the distance to the water surface. Tank level information is transmitted wirelessly back to the TankLink control module installed near your pump controller.
The control module then interfaces with your pump system, allowing the pump to respond automatically to configured tank-level conditions.
Unlike a conventional float switch, there is no float hanging inside the tank and no long control cable running between the tank and pump.
The level sensor is designed for harsh outdoor environments, features an IP66 enclosure, and is powered by a high-capacity replaceable battery. The supplied sensing technology supports remote tank and level monitoring specifically as one of its intended applications
HOW IT WORKS
- Monitor the Tank: The wireless ultrasonic sensor mounts above the water and measures the distance to the water surface without physical contact.
- Send the Tank Level Wirelessly: Tank level data is transmitted over the wireless network to the TankLink control system.
- Control the Pump: The TankLink controller connects to your pump controller and can be configured to respond to predefined tank-level conditions.
- Automatic Operation: For example, the pump can be configured to start when the tank falls below a chosen level and stop when the tank reaches the required full level.
KEY FEATURES
- Wireless tank level control
- No long float-switch cable required
- Non-contact ultrasonic measurement
- Automatic pump start/stop capability
- Suitable for remote tanks and bores
- IP66 outdoor tank sensor
- Long-life replaceable sensor battery
- Wireless communication between tank and control system
- Customisable tank-level trigger points
- Pre-configured for your Outback Solar Pump controller
- Once-off professional configuration included
- Australian setup and support
SPECIFICATIONS
| Specification | TankLink |
|---|---|
| Measurement Type | Non-contact ultrasonic |
| Measurement Range | Up to 5m or 8m configuration |
| Accuracy | High-accuracy ultrasonic measurement |
| Resolution | 1mm |
| Wireless | Long-range wireless |
| Sensor Power | Replaceable 19,000mAh battery |
| Enclosure | IP66 |
| Installation | Tank, wall or pole mounted |
| Operating Temperature | -30°C to +65°C |
| Voltage | 5–24V DC control module power supply |
| Brand | Outback Solar Pumps |
|---|---|
| SKU | ACC-TANKL |
| Voltage | 5–24V DC control module power supply |
| Controller Type | Wireless IoT Pump Control Module |
Downloads coming soon.
Product Downloads
No downloads added yet.
Ideal For
-
Remote Water Transfer Move water where you need it, off-grid.
-
Tank Filling Efficiently fills tanks and storage systems.
-
Livestock Watering Reliable water supply for livestock and farms.
Frequently Asked Questions
Does TankLink replace a normal tank float switch?
Yes. TankLink can provide automatic tank-level control without needing a traditional float switch and long control cable running between the tank and pump.
Does the sensor touch the water?
No. The TankLink sensor uses ultrasonic measurement from above the water surface, so there are no moving floats or probes submerged in the tank.
Does TankLink come ready to use?
Yes. Each TankLink system is configured for your application before dispatch. We set up the communication and control logic required to interface with your compatible Outback Solar Pump controller.
