Outback Trailblazer 3" 1.00kW DC Submersible Centrifugal Bore Pump & Motor (Max 67LPM/93m)

The Outback Trailblazer 3" DC Submersible Centrifugal Bore Pump & Motor is a high-flow replacement pump assembly engineered for applications where maximum water delivery is the priority. Powered by a 1.00 kW DC motor, the Trailblazer delivers up to 67 LPM with a maximum head of 93 metres, making it the highest-flow pump in the Outback 3" range.

Supplied as a pump and motor only, the Trailblazer is ideal as a direct replacement or spare for existing Outback Trailblazer systems, or for users upgrading to higher flow capacity within an existing solar DC setup without purchasing a complete kit.

When bore yield is strong and water demand is high, a centrifugal pump is the correct choice. The Outback Trailblazer delivers rapid water movement, excellent efficiency, and reliable solar-powered performance in high-flow applications.

Keeping a spare Trailblazer pump on hand ensures fast recovery from failures and uninterrupted water supply in critical systems.

Centrifugal Pump Performance Advantage

Unlike helical rotor pumps, centrifugal pumps use high-speed impellers to move water, making them particularly well-suited to:

• Applications requiring high flow rates
• Bores with good water yield
• Situations where rapid tank filling is required

The Trailblazer’s centrifugal design allows it to move large volumes of water efficiently, making it ideal for livestock watering, multiple tank systems, and high-demand transfer applications.

Technical Overview

• Model: Trailblazer
• Pump Diameter: 3 inch
• Motor Power: 1.00 kW (DC)
• Pump Type: Submersible centrifugal
• Maximum Flow: 67 LPM
• Maximum Head: 93 m
• Application: Bore pumping, tank filling, water transfer
• Supply: Pump & motor only (controller, panels & accessories sold separately)

Key Benefits

• Complete pump & motor replacement assembly
• 1.00 kW DC motor optimised for solar operation
• Centrifugal pump design for high-flow performance
• 3" slimline diameter suits narrow bore casings
• Very high flow rate compared to helical rotor models
• Ideal spare pump for high-demand and remote installations

Applications

• Replacement pump for existing Outback Trailblazer systems
• High-yield bores requiring large daily water volumes
• Fast tank filling applications
• Solar DC systems supporting multiple tanks
• Remote installations where downtime is unacceptable


Product Download

• PDF Performance Brochure
