Outback Pioneer 3" 0.60kW DC Submersible Helical Rotor Bore Pump & Motor (Max 18LPM/100m)
Couldn't load pickup availability
The Outback Pioneer 3" DC Submersible Helical Rotor Pump & Motor is a high-head replacement pump and motor assembly engineered for deeper bore applications and demanding solar pumping conditions. Rated at 0.60 kW, the Pioneer delivers consistent performance with a maximum flow of 18 LPM and an extended maximum head of 100 metres.
Designed as a direct replacement or spare pump for existing Outback Pioneer systems, this unit is ideal for customers who require a powerful DC helical rotor pump without purchasing a complete solar kit. Its slimline 3" profile allows installation in narrow bore casings while delivering superior lift capability compared to lower-powered models.
When deeper bores demand higher lift without sacrificing reliability, the Outback Pioneer delivers. Keeping a spare Pioneer pump on hand ensures fast recovery from failures and avoids extended water outages in remote or unattended systems.
Built for efficiency, durability, and dependable high-head performance, the Pioneer is the go-to replacement pump for demanding solar bore applications.
Helical Rotor Advantage for Deep Bores
The Pioneer uses a helical rotor (progressive cavity) pumping design, making it exceptionally effective in high-head, low-yield environments. Unlike centrifugal pumps that lose efficiency as head increases, helical rotor pumps maintain stable flow at depth by positively displacing water upward through sealed cavities.
This design ensures reliable pumping from deeper static water levels while keeping power usage efficient — a critical factor in solar DC systems.
Technical Overview
- Model: Pioneer
- Pump Diameter: 3 inch
- Motor Power: 0.60 kW (DC)
- Pump Type: Helical rotor / progressive cavity
- Maximum Flow: 18 LPM
- Maximum Head: 100 m
- Application: Bore pumping, tank filling, water transfer
- Supply: Pump & motor only (controller, panels & accessories sold separately)
Key Benefits
- Complete pump & motor replacement assembly
- High-power 0.60 kW DC motor for deep bore performance
- Helical rotor design maintains flow at high heads
- 3" slimline diameter suits narrow bore casings
- Ideal spare pump for critical or remote installations
- Designed specifically for solar DC operation
Applications
- Replacement pump for existing Outback Pioneer systems
- Spare pump for deep or critical bore installations
- Low-yield bores with high static water levels
- Solar DC systems requiring higher lift capability
- Remote water supply systems where downtime is costly
