Outback AutoMate Solar 25mm Constant Pressure Headworks Kit
Couldn't load pickup availability
The Outback AutoMate Constant Pressure Headworks Kit is a complete, installer-ready solution designed to convert any solar bore pump system into a fully pressurised water supply. By pressurising the bore delivery line, the AutoMate allows solar pumps to operate reliably with float valves, troughs, and long-distance pipe runs where float switches are impractical or unreliable.
This kit is ideal for applications where:
- The tank or trough is too far away for a float switch
- Long pumping distances create voltage drop or signal issues
- A constant pressure system is required instead of simple on/off control
The AutoMate uses a reverse-acting pressure switch and pressure vessel to automatically start and stop the pump based on system pressure, delivering smooth, stable operation without rapid cycling.
How the AutoMate System Works
When water demand opens (e.g. float valve in a tank or trough), system pressure drops. The reverse-acting pressure switch closes, starting the pump. Once pressure is restored, the switch opens and the pump stops.
The 8L pressure vessel absorbs pressure fluctuations, reducing pump cycling and protecting both the pump and controller.
⚠️ Important:
A check valve must be installed on the suction side of the system, ideally directly on the pump discharge, to prevent backflow and ensure stable pressure operation.
What’s Included (Complete Headworks Kit)
- Reverse-acting pressure switch
- 10m of 0.5mm² 2-core electrical cable (pressure switch wiring)
- 25mm brass 5-way tee with 1/4" ports for gauge & pressure switch
- 1000kPa pressure gauge
- 8L PN10 pre-charged pressure tank
- 25mm brass nipple
- 25mm gate valve
Everything required to build a professional constant-pressure headworks assembly.
Technical Overview
- System Type: Constant pressure headworks
- Pressure Control: Reverse-acting pressure switch
- Tank: 8L PN10 pre-charged pressure vessel
- Pipe Size: 25mm
- Gauge Range: 0–1000 kPa
- Compatibility: All DC solar bore pump systems
- Check Valve Requirement: Mandatory (not included)
- Flow Rate: Suitable up to 80LPM
Key Benefits
- Converts any solar bore pump into a pressurised system
- Ideal for long-distance pumping and remote tanks
- Works with float valves in tanks or troughs
- Eliminates the need for float switches where impractical
- Reduces pump cycling and mechanical wear
- Installer-ready kit with matched components
Applications
- Solar bore pumps feeding distant tanks or troughs
- Installations using float valves instead of float switches
- Long pipe runs with elevation or pressure loss
- Livestock watering systems
- Remote or unattended water supply systems
